- Smooth and fast motions, mold open/close speed reaches 1200mm/s, and the dry cycle time is only 2.3 seconds (Lock to Lock).
- Small deformation due to sturdy design and special structure, so that it decreases flash issues, and prolongs life - span of the mold.
- Unique limit outfit for opening mold ensures the mold opening position more precise.
- Large range of mold height adjustment for wider application.
- The reliable mold protection results from the accurately and rapidly control of the mold, and the application of the hydraulic buffer.
- The flexible design of mold installation and eject pattern offers customer more benefit.
Special designed ejector for PET
- Quick, powerful, and smooth actions. The ejection speed reaches 500mm/s.
- Increases ejector force is helpful to strip off the PET performs.
- Limitation of ejector position favoured for performs taking out by robot.
- Equipped with booster which can offer not only powerful ejector force, but also quick ejection.
Sealed closures of the mold and robot area.
- Decrease day air losing with mould dehumidifier.
- More safety for operations.
Specially designed 2 stage injection unit, separated pre plasticizing and injection unit.
- Less cycle time, higher efficiency.
- Specially designed screw, fir for perform of PET materials.
- Improved injection precision.
- The straight driven nozzle distributor shortens the switch time.
Precise controller with high speed, make it easy to operate. Multiple languages in.
- World famous brand controller.
- PTD control for barrel temperature.
- Mould temperature controller is integrated with the main control system. This system leads is easy operations and precise temperature control.
Multiple loops hydraulic system.
- Specially designed hydraulic system implements multi-loop simultaneously, shortening cycle time.
- Separated plasticization actions ensure high perform quality.
- High response, precise control.
- Closed loop control if serve valves equipped.
